VYCOR® Weather Barrier & Flashing Tapes

Durable, energy-efficient and easy to install.

Worsening weather is a global phenomenon.

Hurricanes, wind driven rains and climate change. The specifics of location don't matter anymore — no matter where a home is built, it's likely that it will endure many severe weather events during its lifetime. Over the long term, this means resisting water infiltration. Water infiltration at vulnerable window and door openings can lead to rot and mold, which can endanger both a structure and its inhabitants.

Documents

VYCOR® Product Documents

Product Name Product Data Sheet Guide Specifications SDS/MSDS
Vycor® Aluminum Flashing
Product Data Sheet
SDS/MSDS
Vycor® Deck Protector®
Product Data Sheet
VYCOR® enV™
Product Data Sheet
Guide Specifications
SDS/MSDS
Vycor® Plus
Product Data Sheet
SDS/MSDS
Vycor® PRO
Product Data Sheet
Guide Specifications
SDS/MSDS
VYCOR® V40
Product Data Sheet
Guide Specifications
SDS/MSDS

Detail Drawings

Product Name PDF
VCR-100 — Flashing after WRB Installation Detail Drawing
VCR-107 — Flashing Tie-in with Vinyl Siding Detail Drawing
VCR-200 — Flashing Sliding Window Detail Drawing
VCR-201 — Flashing Exterior Door Sill Detail Drawing
VCR-300 — Deck to Wall Detail Drawing
VCR-400 — Stucco Window Head Detail Drawing
VCR-401 — Stucco Window Sill Detail Drawing
VCR-402 — Stucco Parapet Wall Detail Drawing
VCR-403 — Stucco Pot Shelf Detail Drawing
VCR-500 — Outside Corner Detail Drawing
VCR-502 — Inside Corner Detail Drawing
VCR-505 — Foundation Sill Plate (Option 1) Detail Drawing
VCR-506 — Foundation Sill Plate (Option 2) Detail Drawing
VCR-507 — Vycorner Detail Drawing
VCRDET- 101 — Flanged Window Low Exposure (Option 1) Detail Drawing
VCRDET- 102 — Flanged Window - AAMA Reccomendation Detail Drawing
VCRDET- 103 — Flanged Window Severe Exposure (Option 3) Detail Drawing
VCRDET- 104 — Half Round Window - Low Exposure (Option 1) Detail Drawing
VCRDET- 105 — Half Round Window - Severe Exposure (Option 2) Detail Drawing
VCRDET- 106 — Window Sill Pan Options Detail Drawing
VCRDET- 107 — Tie-In with Vinyl Siding Detail Drawing
VCRDET- 108 — Recessed Window Detail Drawing
VCRDET- 109 — Window Without Nailing Flange (Wood/Steel Frame Construction) Detail Drawing
VCRDET- 110 — Window Without Nailing Flange (Concrete/Masonry Construction) Detail Drawing
VCRDET- 201 — Sliding Door with Deck Detail Drawing
VCRDET- 300 — Joist Hanger Protection Detail Drawing
VCRDET- 400 — Stucco Window Head Detail Drawing
VCRDET- 401 — Stucco Window Sill Detail Drawing
VCRDET- 402 — Stucco Parapet Wall Detail Drawing
VCRDET- 403 — Stucco Pot Shelf Detail Drawing
VCRDET- 500 — Outside Corner Detail Drawing
VCRDET- 501 — Wall to Wall Outside Corner Detail Drawing
VCRDET- 502 — Inside Corner Detail Drawing
VCRDET- 503 — Wall to Wall Inside Corner Detail Drawing
VCRDET- 504 — Corner Detailing Patch Options Detail Drawing
VCRDET- 505 — Foundation Sill Plate (Option 1) Detail Drawing
VCRDET- 506 — Foundation Sill Plate (Option 2) Detail Drawing
VCRDET- 507 — Vycorner Options Detail Drawing
VCRDET-100 — Flashing After WRB Installation Detail Drawing
VCRDET-111 — Flanged Window after WRB (Option 2) Detail Drawing
VCRDET-200 — Exterior Door Sill Detail Drawing
VCRDET-301 — Top of Joist Detail Drawing
VCRDET-302 — Column/Post Base Detail Drawing
VCRDET-303 — Top of Post/Below Grade Detail Drawing
VCRDET-304 — Tension Tie Downs/Sill Plate Detail Drawing

Product Brochures

Product Name PDF
VYCOR® enV® Product Brochure
VYCOR® Plus Tear Sheet
Products & Accessories

Products

  • Product Name
  • Description
  • Key Benefits
  • Applications Type
Vycor® Deck Protector®
Description

Vycor® Deck Protector is a self-adhered membrane, formulated and tested to solve the problems of joist rot and deck corrosion.

Key Benefits
  • Self-adhering membrane for fast, easy installation
  • Prevents water infiltration at deck fasteners – seals around fasteners
  • Skid-resistant coating for foot traffic during installation
  • Compatible with all decking materials
  • Fast and easy to install
  • Handy roll sizes
  • Versatile – useful for other non-roof flashing details
  • Convenient measurement markings
Application Type
  • Deck Joists
  • Deck Ledger Boards
VYCOR® enV-S™
Description

VYCOR® enV-S™ represents the next generation of weather resistive barriers and is designed to provide superior weather protection, and improved energy performance. The membrane brings together the weather protection benefits of a self-adhered membrane, with the breathability of traditional housewraps. The unique adhesive coating bonds strongly to the sheathing, but remains vapor permeable. VYCOR® enV-S™ resists damage in windy conditions, leading to less rework and a high quality appearance.

Key Benefits
  • Water resistive barrier
  • Seals around nails
  • Vapor permeable
  • Air resistive
  • Easy to install
Application Type
  • Weather barrier installed on structural sheathing
  • Residential, multifamily, and low rise commercial buildings
  • New construction, renovation, and re-siding application
  • Not for rooftop applications
VYCOR® enV™
Description

VYCOR® enV™ is a rolled or spray-applied, one component, acrylic membrane that forms a continuous water and air barrier with seamless protection. VYCOR® enV™ protects against ingress of incidental water caused by severe weather, vapor or condensation. VYCOR® enV™ protects moisture sensitive wood structures from damage in the event of a breach in exterior wall coverings.

Key Benefits
  • Water resistant
  • Air resistant
  • Vapor permeable
  • Fully bonded
  • Seamless
  • Easy installation
  • Low odor and VOC
  • UV resistant up to 4 months
Application Type
  • Weather Barrier installed on structural sheathing
  • Residential, Multifamily, and Low Rise commercial buildings
  • New construction, renovation, and re-siding application
  • Not for rooftop applications
Vycor® Plus
Description

Vycor® Plus self-adhered flashing is composed of durable, crosslaminated, high-density polyethylene sheet, backed by an aggressive, pressure-sensitive rubberized asphalt adhesive.

Key Benefits
  • Ripcord® split release on demand
  • Easier and faster to install correctly
  • Seals around nails
  • Thin (25 mil) membrane is highly conformable
Application Type
  • Window and door openings (headers, sills, jambs, thresholds, nailing flanges)
  • Deck-to-wall intersections
  • Inside and outside corners of sheathing
  • Wall-to-wall tie-ins
  • Foundation sill plates
Vycor® PRO
Description

Vycor® Pro flashing, with its highly conformable film and butyl-modified adhesive technology, provides premium protection against water infiltration in all critical non-roof detail areas. Vycor® Pro contains no asphalt and is compatible with flexible PVC window flanges and leading sealant technologies.

Key Benefits
  • Non-asphaltic butyl-modified adhesive
  • Seals around nails
  • Highly conformable thin (14 mil) membrane
  • Convenient measurement markings
Application Type
  • Window and door openings
  • Deck-to-wall intersections
  • Inside and outside corners of sheathing
  • Wall-to-wall tie-ins
  • Foundation sill plates

Accessories

  • Accessory Name
  • Description
  • Key Benefits
  • Applications Type
Vycor® Aluminum Flashing
Description

Vycor® Aluminum Flashing self-adhered flashing is composed of durable, cross-laminated, high density polyethylene aluminum surfaced sheet, backed by an aggressive, pressure sensitive rubberized asphalt adhesive.

Key Benefits
  • Ripcord® split release on demand
  • Easier and faster to install correctly
  • Improved product performance
  • Proper integration with housewrap, felt and other weather resistive barriers
  • Reduces the risk of rot and mold development
  • Provides waterproofing protection for leak areas where flashing is left exposed
  • Seals around nails
Application Type
  • Window and door openings (headers, sills, jambs, thresholds, nailing flanges)
  • Deck-to-wall intersections
  • Inside and outside corners of sheathing
  • Wall-to-wall tie-ins
  • Foundation sill plates
  • Sheathing panel seams
  • Under stucco finishes
  • Masonry walls
  • Other non-roof detail areas
VYCOR® V40
Description

VYCOR® V40 self-adhered flashing is composed of two waterproofing materials—rubberized asphalt and cross-laminated polyethylene. The product is designed to meet the requirements for weather-resistive barriers as defined by Federal Specification UU-B-790a, Grade A.

Key Benefits
  • Premium protection against air, water and moisture infiltration
  • Protects critical non-roof detail areas including masonry walls and stucco
  • 40 mil thick
Application Type
  • Window and door openings (headers, sills, jambs, thresholds, nailing flanges)
  • Deck-to-wall intersections
  • Inside and outside corners of sheathing
  • Wall-to-wall tie-ins
  • Foundation sill plates
  • Sheathing panel seams
  • Under stucco finishes
  • Masonry walls
  • Other non-roof detail areas
Overview

Stand up to the worst that weather can offer

Traditional weather barrier and flashing systems aren't well suited to the challenges that a worsening climate may present. Even if a housewrap is correctly applied to the substrate—a laborious and error-prone process of taping and fastening—installation of siding and trim will penetrate the wrap with thousands of holes. Each nail or staple that penetrates the wrap represents an area where water can infiltrate and cause damage. Each home includes 20 or more large holes (windows), and each of these vulnerable areas needs to be protected. Mechanically attached flashings or building paper do not seal off these areas from wind-driven rain, and caulks dry and become brittle with time.

VYCOR® represents the best solution for a house's longevity in the face of weather. As a fully-adhered weather barrier and flashing system, the products seal to the substrate, seal at overlaps, and seal around the fasteners that attach siding, trim, and decorative features. VYCOR® weather barriers and flashing deliver robust and worry free protection for the owner, and are easy for the contractor to install. VYCOR® weather barriers and flashing tapes are made in the USA by GCP Applied Technologies, the inventors and manufacturers of Grace Ice & Water Shield®.

Great for homeowners, great for contractors

For homeowners, VYCOR® weather barrier and flashing tapes serve an important dual purpose—keeping water out, preventing structural damage, and reducing air leakage which saves money on heating costs. For contractors, not only are VYCOR® products easy to install they also provide homes under construction with a clean, sleek, professional appearance that says “I am a high quality builder” to potential drive-by customers.

A safer and more comfortable home

Preventing water infiltration and leaks is critical to preventing mold and rot, and to protecting the home’s structural integrity. Preventing air infiltration is also critical to maintain comfort, indoor air quality, and energy efficiency. Air leakage into and out of the building causes the HVAC system to work harder, and higher utility bills. VYCOR® weather barriers and flashing tapes have been proven by Oak Ridge National Labs to deliver 7 times lower air leakage than a leading house wrap brand. This results in up to 56% lower heating and cooling costs.

Stands up to the rigors of construction

VYCOR® weather barriers and flashings don’t only protect the house in the long run, eliminating call-backs due to leaks, but it also protects the house during construction. Before being covered with siding, a mechanically-attached house wrap can act like a sail in the wind. Instead of tearing in the breeze, VYCOR® weather barriers and flashings stay put, lending a clean and professional appearance during the construction process while standing up to jobsite conditions.

Technical and field support

VYCOR®'s reputation is backed by a thorough commitment to service. Experts from GCP are available to answer any questions about the installation or performance of VYCOR® weather barriers or flashings.
