Project Profile
Expanding pharmaceutical plant
Due to strong demand for its products, a pharmaceutical company invested in expanding the production capacity at its Ware site in the UK. Part of this project was to increase the size of the commercial building and to incorporate new production lines.
The project engineers at the facility needed to install new air conditioning as well as electrical and mechanical systems into new plant rooms. They decided to construct new steel gantries approximately 50 cm above the existing building roof to provide the structural base for the new plant rooms, which were supported by extending 18 steel columns through penetrations cut through the existing roof.
Since the penetrations needed to be sealed and access to the existing roof would be restricted, the project team decided to re-waterproof the entire roof.
Finding the right roof waterproof solution
A key project requirement was to complete the work without disrupting production at the plant. This meant that the penetrations through the roof had to be cut and sealed with a new roof waterproofing system that would immediately prevent any water entry. The chosen waterproofing system also needed to be applied to the commercial building’s old mastic asphalt roof, which was more than 10 years old.
GCP Applied Technologies was selected to waterproof both the penetrations and the existing commercial building roof coverings. GCP proposed installing its SILCOR® liquid waterproofing system.
Putting waterproof solution to the test
The pharmaceutical facility was concerned about the risks of immediately sealing the column penetrations, so a mock up commercial building construction was built. The mock up was waterproofed and tested after 12 hours for water tightness, with a high-pressure jet washer. The test showed that the SILCOR® liquid waterproofing achieved a highly effective seal around the columns.
GCP chose SILCOR® liquid waterproofing because it adhered to both steel and mastic asphalt, enabled continuation of roof vapor control layer and insulation, and resisted water penetration within two hours of application to the steel columns.
SILCOR® 900HA hand-applied membrane was used to seal the 18 column penetrations and SILCOR® 900MP spray-applied membrane was used to re-waterproof the mastic asphalt roof.
Blue360sm Product Performance Advantage.
