ELIMINATOR® bridge deck waterproofing membrane

Extending the life of road and railway bridges

Overview

Superior protection for bridge decks

Steel and concrete bridges are vulnerable to attack by water, chloride and frost, leading to deterioration and even structural failures. Installing a high-performance waterproofing membrane is therefore an essential part of any bridge construction or refurbishment program. The ELIMINATOR® bridge deck waterproofing membrane is a cold, spray-applied solution that can outlast the life of the structure — reducing maintenance costs and traffic disruptions.

Achieve long-term performance

The ELIMINATOR® bridge deck waterproofing membrane has an unparalleled track record protecting thousands of concrete and steel bridges throughout the world. Based on unique ESSELAC® advanced resin technology, the system creates composite action between the deck, waterproof membrane and asphalt, ensuring that the membrane is fully bonded both downwards to the deck and upwards to the surfacing. The extremely high bond enables the membrane to stand up to punishing climate conditions and heavy traffic loads.

Accelerating waterproofing application

The ELIMINATOR® bridge waterproof membrane offers fast, simple and effective application. Unlike alternative solutions that are sensitive to moisture, the ELIMINATOR® membrane can be applied virtually year round, in any climate, preventing costly weather delays. It cures in just an hour, even in high humidity or low temperatures. In addition, the system features on-the-spot QA capabilities, such as the two-color application system, that make it easy to quickly verify that the membrane is applied properly.

Product advantages

  • Long lasting, highly durable membrane drives down future maintenance costs
  • Fast application (in excess of 2,000m2 per day) with industry-standard equipment
  • No need for hot trades
  • Requires minimal surface preparation
  • Approved Contractor Program and onsite quality control measures ensure the integrity of the membrane prior to surfacing
  • Elimination of critical overcoating time allows phasing of work for greater scheduling flexibility
  • Unaffected by application of surfacing up to 250°C

Products & Accessories

Products

Cold applied waterproofing

Waterproofing accessories

  • Product Name
  • Description
  • Key Benefits
  • Applications Type
ELIMINATOR® Data Sheet

Cold applied waterproofing

Description

ELIMINATOR® is a high performance waterproofing membrane for the protection of concrete and steel bridge decks based on Stirling Lloyd, now GCP’s unique ESSELAC® advanced resin technology and extensive experience in the development of coatings for specialist waterproofing.

Key Benefits
  • Long and effective life
  • Able to withstand high humidity and cures rapidly even at low temperatures enabling all year round application
  • Rapid application and re-access
Application Type
  • Concrete Bridge Decks
  • Steel Bridge Decks
  • Bridge Piers
  • Bridge Service Ducts
  • Culverts
Primer MR6 Data Sheet

Waterproofing accessories

Description

PRIMER MR6 is a two component, fast curing, high strength acrylic reactive resin. It is formulated to form a cohesive bond with the substrate.

Key Benefits
  • Excellent bond to substrate
  • Bond test allows for on site quality assurance
  • Low viscosity suitable for brush, roller and spray application
Application Type

PRIMER MR6 can be brush, roller or spray applied. The appropriate amount of Hardener Powder is determined by the Stirling Lloyd Mixing Guide and is a function of the material and substrate temperature. The Hardener Powder is added to the resin and thoroughly dispersed. Due to the material’s relatively short pot life, only make enough material that can be applied in five (5) minutes.

Accessories

Waterproofing accessories

  • Accessory Name
  • Description
  • Key Benefits
  • Applications Type
TACK COAT SA1030 Data Sheet

Waterproofing accessories

Description

Tack Coat SA1030 is a polymer-modified bond coat, applied over the ELIMINATOR® waterproofing membrane to provide a very strong bond between the membrane and hot bituminous road surfacing.

Key Benefits
  • Provides an excellent bond between the ELIMINATOR® waterproofing membrane and the surfacing
  • Solidifies rapidly after application
Application Type
