Waterstops

Flexible waterproofing for concrete joints.

The way to a better waterstop

Waterstops represent a critical component of any waterproofing system. Due to shrinkage and settling, the surfaces of a concrete cold joint will never perfectly conform to one another. Without a flexible barrier that can accommodate the imperfections  of concrete surfaces, water will have the opportunity to creep in through the seam.

The GCP advantage

Our waterstops are specifically designed to resist job-site conditions while outperforming other solutions. These waterstops offer innovative technology options  to meet a wide variety of project needs. This includes tricky or problematic installations where technical finesse is required. No matter the project, we have a waterstop that’s ideal for the job.

Overview

Waterstop Solutions

Our solutions incorporate advanced materials that prevent water infiltration in ways that other waterstops can't.  Novel engineering technologies result in waterstops that conform more securely to concrete surfaces, last longer, and provide more flexibility to contractors. For more information about these and other waterstop solutions, contact GCP today.

ADCOR®

An advanced hydrophilic waterstop that's compatible with all of our  industry-leading waterproofing membranes. ADCOR® is engineered to expand when it comes in contact with water. The material seals against concrete faces when encapsulated, and resists water infiltration through a cold joint.

INJECTO® Tube Groutable Hose Waterstop System

An injectable waterstop system that provides a passageway for a variety of chemical grouts. The system is designed to be laid down before concrete is poured, but not injected until well after it has cured. This allows the cracks created by shrinkage during the curing process to fully open. The resulting interfaces and voids can then be permanently sealed.

TRIOject® Multiple Grout Injection Hose

Comprised of a three-channel PVC-hose, TRIOject® allows for multiple grout injections in a more durable enclosure. Each of the three grout channels contains micro holes that prevent water from getting in, but allow grout to escape. The system is protected by a steel mesh on top, as well as a foam pad on the bottom that conforms to the concrete surface.  Crucially, the three-channel TRIOject® design lets builders in ject the same cold joint multiple times—a best-in-class solution for a critical or problematic application.

Product Warranty

Click on the login to access the site with your username and password. Please add GCPAT\ (including the slash) in front of your user name when entering user name.

If you need assistance, please contact Denise White at: 617 498-4555 or Denise.I.White@gcpat.com

Product Listing
  • Product
  • Description
  • Key Benefits
  • Applications Type
Adcor® 500T
Description

Adcor® 500T is a unique product that has been specifically developed to provide higher performance than conventional bentonite or swellable rubber waterstops.

Key Benefits
  • Controlled volumetric expansion
  • Conformable
  • Retains cohesive strength at both original and expanded volume.
  • No need for protective steel mesh.
Application Type
  • Horizontal and vertical construction joints
  • Casting new concrete against existing
  • Floor slabs cast against diaphragm retaining walls, steel sheet piles and secant pile walls
Adcor® ES
Description

Adcor® ES is a specially engineered, swellable, conformable synthetic waterstop strip that expands when in contact with water. The engineered swell design of Adcor ES minimizes the potential for concrete spalling and cracking versus traditional hydrophilic waterstops.

Key Benefits
  • Controlled, reproducible, volumetric expansion
  • Cohesive strength maintained after volumetric expansion and during wet-dry cycling
  • Malleable and plastic
Application Type
  • Horizontal and vertical construction joints in concrete structures
  • Casting new concrete against existing
  • Pipe penetrations through floors and walls
De Neef® INJECTO® SIS Tube
Description

The Small Injection System (SIS) INJECTO® is an injectable waterstop system that provides a conduit for the placement of DeNeef chemical grouts. Like its big brother the Injecto hose, the SIS hose is a permeable tube designed to ensure even distribution of grout throughout the injection zone.

Key Benefits
  • Small hose diameter
  • Fast, simple installation
  • No special tools required
  • Low pressure injection
  • Permanent seal after injection
  • Injectable anytime after concrete cure
Application Type
  • Sealing cold and construction joints
  • Sealing pipe penetrations
  • Sealing joints between slurry walls and slabs
INJECTO® Tube
Description



INJECTO® is an injectable waterstop system that provides a conduit for the placement of GCP approved chemical grouts.

Key Benefits
  • Fast, simple installation
  • No special tools required
  • Low pressure injection
  • Permanent seal after injection
  • Injectable anytime after concrete cure
  • INJECTO® System Warrenty
Application Type
  • Sealing cold and construction joints
  • Sealing pipe penetrations
  • Sealing joints between slurry walls and slabs



INJECTO Tube may only be used with GCP approved chemical grouts. The various grouts available depend on site conditions and other requirements. Contact your local sales representative or technical service consultant to determine the best grout needed for your application.



TrioJECT
Description

TRIOject is a multiple injection grout hose. It consists of three injection channels capable of being grouted independently. Each channel can be injected as needed through a Vario Packer. Pressure activated apertures on the top and bottom of the channels allow the injected grout to permeate the joint. The foam pad on the bottom assures continuous access to the concrete surface.

Key Benefits
  • Three independent injection channels
  • Pressure activated apertures
  • Durable construction
  • Wire mesh for additional protection
  • Foam pad adapts to irregular surface
Application Type

Sealing of construction joints, cold joints and working joints in concrete, where reinjection may be necessary
